Electrolytic Coating Lines

Electrolytic Tinning Line

Strip  Thickness：  0.11—0.5mm

Strip      Width：  500—1200mm

Working    Speed：  60—180m/min

Process   Method：  Ferrostan Method

Product Standard：  GB/T 2520-2000

Electrolytic Galvanizing Line

Strip  Thickness：  0.12—0.8mm

Strip      Width：  800—1250mm

Working    Speed：  25—80m/min

Process   Method：  Sulfate Process

Product Standard：  GB/T 15675-1995

Process Flow

Pay-off Reel---Pinch Roll---Shear---Welding Machine---Tension Roll ---Entry Looper---Tension Roll---Chemical Rinsing System---Electrolytic Degreasing System---Spray Washing System---Pickling Section--- Electroplating Tank---Conditioning Section---Hot Air Blowpipe---Tension Roll (---Melting Brighten for ETL)---Passivation Tank---Drying Oven---Tension Roll---Exit Looper---Tension Roll---Pinch Roll---Electrostatic Oiler---Shear---Pinch Roll ---Recoiling Machine
