Push-pull Pickling Line

Parameters

Strip    Material：    Q195，Q235，08AL

Strip   Thickness：    2—4mm

Strip       Width：    300—800mm，800—1250mm

Working     Speed：    60—120m/min

Process    Method：    Push-Pull Pickling

Process Flow

Pay-off Reel----Leveler with Pinch Roll----Vertical Guide Rollers----Shear----Inclined Throat Shears----Scrap Bucket Car----Vertical Guide Rollers----Precleaning----Pickling Section----Spray Washing System----Vertical Guide Rollers---Pinch Roll----Looper----Steering Machine----Trimming Shears----Taking-up Machine---Pinch Roll ----Three-roll Tension Machine----Shear---- Pinch Roll---- Recoiling Machine
